Phoenix Contact AC Charging Cable | 5m | Type 2

Name: Phoenix Contact AC Charging Cable | 5m | Type 2
SKU: PHX-CABLE-AC
Availability: BackOrder

$398.94

Available on back-order

Availability: onbackorder

QUICK OVERVIEW

Mobile AC charging cable with vehicle charging connector and infrastructure charging plug for charging EVs with AC via type 2 vehicle charging inlets, compatible with type 2 infrastructure charging sockets at charging stations for e-mobility.

SKU: PHX-CABLE-AC

M1642 01

Item number 1285622
Packing unit 5 pc
Minimum order quantity 120 pc
Sales key XWBAEC
Product key XWBAEO
GTIN 4063151492366
Weight per piece (including packing) 22.22 g
Weight per piece (excluding packing) 22.22 g
Customs tariff number 85444290
Country of origin PL

Electrical properties
Type of signal transmission Pulse width modulation
Note on the connection method Crimp connection, cannot be disconnected
Coding 220 Ω (between PE and PP)
Type of charging current AC 3-phase
Charging power 26.6 kW
Charging current 32 A
Power contact
Number 5 (L1, L2, L3, N, PE)
Rated voltage 480 V AC
Rated current 32 A
Signal contact
Number 2 (CP, PP)
Rated voltage 30 V AC
Rated current 2 A
Dimensions
Width 57 mm
Height 77.5 mm
Depth 193.3 mm
